Personnel Door

Economical Personnel Access Doors

Cost-efficient pressed colour steel panel doors of distinction.

Personnel Doors

The Personnel Door has been developed as a cost-efficient access door for steel frame sheds, barns, and domestic garages. We have used the latest construction technology to provide a product that will enhance any door opening in your building.

Key specifications


  • Universal hanging – either L/H or R/H hanging by simply rotating the complete door around
  • Attractive flush face door appearance with no ugly perimeter channels or rivet fixings
  • High density polyurethane foam core giving a high impact resistant colour steel face
  • A solid 3.0mm wall thickness for secure hinge fixing points
  • Eliminates all swelling, sticking and painting problems associated with timber doors
  • Heavy duty stainless hinges and quality Guardsman stainless steel locksets are used
  • Quality fitting for a quality door
  • Low maintenance, no painting required
  • Available in any colour steel colour range
  • The finished door is completely covered in Polystyrene packaging and shrink wrapped eliminating all freight damage
  • A PVC protective film is placed on the coloursteel face of the door to avoid any installation damage
  • Totally enhances and finishes off any opening in your building
  • Quick installation time

Enquire about Personnel Doors

Interested in using our Personnel Doors for your next project? Talk to one of our specialists today to discuss how we can customise your site.

Personnel Door

UTM Parameters

Tech Specs


Door set shall be “PERSONNEL DOOR” as supplied by AceDoor System 2013 Ltd.

Maximum trimmed opening sizes:

Single leaf doors: 2300mm high x 1100mm wide


A. .40mm thick door leaf

B. Clad in .59 G2 ColorSteel with mill finished aluminum channels

C. Door leaf injected with polyurethane

D. PA Door with frame – Leaf is fitted with 3 x heavy-duty butt hinges

E. PA Door without frame – (Leaf only) is fitted with 3 x 304 Grade Stainless Steel Hinges


Optional robust aluminum profiles designed to overlap daylight opening of the doorway and fit on the outside face of the wall.


A. Hardware is factory fitted.

B. Standard hardware and furniture are Schlage R51 Denver

C. Optional non-standard hardware available at additional cost, including Motorhome Latch, Lever Handle.


Standard ColorSteel range to suit your colour requirements.


A. Vision Panel – standard Sizes 500mm x 500mm and 800mm x 200mm

  • Using 4 or 6mm toughened glass (special sizes available)

B. S/S kick Plates

Manufacturing Quality

With over 30 years’ experience in the market, we know how to deliver a product with longevity, with less overall maintenance requirements, and lower temperature loss, resulting in greater energy savings.

Manufactured from our Auckland Factory

All our Personnel Doors are made and manufactured in our Auckland factory, adapted to the site and requirements of the individual client. With your needs in mind, we have the agility and experience to deliver an exceptional product at a competitive rate with outstanding service.
