PVC Swing Doors
For heavy-duty trolley and pallet traffic, doors must be especially strong and resilient. RUDNEV™ Door Systems double-action swing doors provide a high level of durability and impact-resistance for these demanding situations.
Product Features
RUDNEV™ Door Systems PVC impact doors are available in one and two-leaf models. They include hinge hardware, with fully-adjustable tension spring and smooth operating self-closing hinges. Rudnev™ manufacture the doors in our Penrose factory.
We manufacture two types of PVC swing door - Hygiene™ and Clear-Vu™.
The Hygiene™ swing door is suited to personnel use rather than forklifts.
Hygiene™ Swingdoor Maximum Sizes
Single 2.4 high x 1.2 wide
Double 2.4 high x 2.0 wide
The Hygiene™ swingdoor incorporates a heavy-duty anodised aluminium door blade, 7mm thick PVC blades, and buffer strips. Used in supermarkets, shops, restaurant kitchens, coolrooms and freezer, hospitals etc.
The Clear-Vu™ swing door is suited to heavy duty use, for example occasional forklift use rather than forklifts.
Clear-Vu™ Swingdoor Maximum Sizes
Single 3.0 high x 1.5 wide
Double 3.0 high x 3.0 wide
The Clear-Vu™ swingdoor incorporates a steel roll-formed door blade (standard hammertone grey finish), 10mm thick steel mounting frame, 7mm thick PVC blades, and buffer strips. Options include gravity flaps above the door, and stay open hinges.
Other Options:
- Buffer strips for high impact areas
- Electrical Activation
- Smoke and dust seals
Product Gallery
Documents
- CAD Drawings: cad-drawings/category/pvc-doors
